Kishan Ganga Hydroelectric Power Project / India

Period: 2009-2018

Customer: NHPC Ltd. Indien

Country: Indien

Technical Description:

The Hydro-power station at the Kishan Ganga River in Kashmir/India consists of a 37 m high concrete-face-rockfill dam, a 24 km long headrace-tunnel followed by penstocks, which lead to the cavern-powerhouse 1with 3 Pelton-units of 110 MW each.

The scope of work of DSD NOELL comprises of the engineering, manufacturing, installation and commissioning of:

  • 1 diversion tunnel roller gate  incl. winch-hoist 1220 kN  (W=8,20m x H=9,50 m)
  • 3 low level spillway radial gates (W=7,00m x H=9,50m) with hydraulic hoists and heating system
  • 1 set of stoplogs (4 elements) (W=7,00m x H=11,50m) with
  • Gantry Crane of 220 kN capacity
  • 2 sliding gates with winch-hoist 50 kN  and heating system for flushing of debris & ice (W=4,25m x H=1,20m)
  • 2 roller gates for power intake with winch hoist 125 kN ( W=4,25m x H=2,50m)
  • 2 slide gates for maintenance of power intake ( W=4,77m x H=2,70m)
  • 2 sets of power intake trash-racks
  • 1 surge shaft roller gate with winch-hoist 300 kN (W=4,10m x H=5,10m)
  • 1 draft-tube outlet slide gate (W= 8,20m x H=9,50m) with
  • Gantry crane 80 kN capacity
  • 3 sets of adit-gates to head-race tunnel (W=2,50m x H=2,50m )
  • main distribution board and automatic gate operation system SCADA
  • 1 Diesel generator 650 kVA
